ADP®Evaporator Coils

ADP® V Series V48H175P389 Horizontal Evaporator Coil With Top Connection, 3 to 4 ton, 48 MBtu/hr

Mfg Part #: V48H175P389

Part #: ADPV48H175P389

Sold As: 1/Each

CPN: Add CPN

Email counter Request quote

Specifications

ManufacturerAdvanced Distributor Products

BrandADP®

Mfg Part #V48H175P389

Part #ADPV48H175P389

Sold AsEach

Package Qty0

Min Order Qty1

Weight0.0

Standards/ApprovalsAHRI Certified|cULus Listed

Description

ADP® Horizontal Evaporator Coil, V Series, 48 MBtu/hr, Tonnage: 3 to 4 ton, R-22, R-410A Refrigerant, 7/8 x 3/8 in Connection, ODF x ODF Connection, 500 psi, 31-1/2 in L x 21 in W x 17-1/2 in H

The V Series premier evaporator coils match perfectly with your system, providing an upgrade over standard matched coils. The V Series is uniquely designed to save customers time on installation while ensuring a leak-free system.

Features

FlexCoil: Engineered for all refrigerants
Dedicated horizontal coils offer strategic attic solutions over standard MP coils
Top refrigerant connections eliminating counter flow and line re-routing
Dual condensate drains on each side for additional installation flexibility
Top panel with only four screws for fast and easy coil access
