EatonPower Receptacles

EATON 270V Duplex Receptacle, 125 VAC, 15 A, 2 -Pole, 3 -Wire, Ivory, NEMA 5-15R

Mfg Part #: 270V

Part #: CWD270V

Sold As: 1/Each

CPN: Add CPN

Email counter Request quote

Specifications

ManufacturerEaton

BrandEaton

Mfg Part #270V

Part #CWD270V

Sold AsEach

Package Qty0

Min Order Qty1

Weight0.0

Standards/ApprovalsFederal Specification Classification 6233 01|NAFTA Compliant|NOM Certified|RoHS Compliant|UL Listed

ApplicationCommercial/Residential

Description

EATON Duplex Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Residential Grade, NEMA Rating: NEMA 5-15R, Grounding Grounding, Side and Push Wired Terminal, 14 to 10 AWG Conductor, Flush Mounting, Screw Connection, Thermoplastic Housing, Brass Contact, Ivory, 1.31 in Length, 0.69 in Width, 4.19 in Height, Additional Information: 14 lbf-in Torque Rating, Core Pack Packaging Type

Features

Longer, wider strap provides 40% more contact area to wall board
Virtually eliminates floating installations
Screw-Catch™ feature automatically holds the wallplate and mounting screw in place
Built-in wire stripper for #14 and #12 wire provides backup for misplaced toolsHigh impact-resistant thermoplastic face and back body eliminates job site breakage
