mr. steam® E-Series 12kW 240V 1-Phase 575 cu. ft Stainless Steel Tank Steam Bath Generator

Description

Steam Bath Generator, Power Rating: 12kW, Voltage Rating: 240V, Amperage Rating: 50A, Phase: 1, Maximum Cubic Feet: 575 cu. ft, Control: Electronic Water Level, Cable Size: 6 AWG, Connection Size: 1/2 inch NPT Steam Outlet, 1/2 inch NPT Drain, 3/8 inch NPT Water Supply, 3/4 inch NPT Safety Valve, 1/2 inch NPT Steam Head, Material: Stainless Steel Tank, Dimensions: 19-1/2 inch W x 7-7/8 inch D x 18-3/4 inch H, Warranty: Limited Lifetime for Generator Parts, Standards/Approvals: cULus Listed, CE and NOM Certified

Features

• Installs in areas such as a cabinet, closet, under a sealed bench or in an insulated attic
• Exclusive micro processor operating system is the brains of our intelligent steam generator
• Easily install spa therapy accessories or components such as AromaTherapy, ChromaTherapy, SteamLinx, and more
• LED indicators to help you troubleshoot any connection and maintenance challenges
• Naturally corrosion resistant, 100% recyclable stainless steel inside and out
• Designed to save water and energy. Uses less than 2 gal of water vs 40 gal for an ordinary bath
• 60 min automatic cut-off, low voltage board, designed for easy access and safe service
• Reliable, industrial grade, and the industries largest copper heating element heats fast and is easy to remove and service
• All MS generators work with all MrSteam controls and with the SteamLinx mobile app
• Our water solenoid technology ensures that the generator is whisper-quiet and never hammers or hums
• Compact, easy to install, and about the size of a large briefcase. Requires zero clearance, so it can be placed flush against the wall
• Maintains constant steam by introducing just the right amount of water through a proprietary dispersal chamber
• Free from defects in materials and craftsmanship for its lifetime. MrSteam will repair or replace (at its option) a Generator which fails to conform to this warranty
• Modular plug and play connections
• Electronic water level control system
• Full port drain valve
• Built-in, low-voltage 24V control
• ASME safety valve
• 60 min electronic countdown shutdown with 75 min limiting safety back-up
