Rheem® Water Heater Booster for Electric or Gas Tank 120° Preset Outlet Temp., Hot Water Increase up to 45%

Description

Water Heater Booster, Electric or Gas Tank, Install: Inline or Wall Mount, Indoor, Minutes of Hot Water in Shower: 45% Increase, Power Supply: 240 Volt, Single Phase, 7.2 kW, 30 AMP Double Pole Max. Breaker, 120° Preset Outlet Temp., 3/4 inch FNPT inlet with 3/4 inch MNPT outlet Water Connections, Dimensions: 8-1/4 inch H x 12-5/8 inch W x 3-5/8 inch D, Activation Temperature: 80-130°F, Outlet Temperature: 80-140°F, Warranty: 5 Year Primary Warranty, Standards: ANSI/NSF 372 by WQA ETL listed to UL 499/CSA

The Rheem Water Heater Booster installs directly on a tank’s hot water line to provide more hot water than the tank alone can provide. The booster delivers nearly double the shower time. The unit senses the temperature of the water from the tank outlet, and activates when it senses that its inlet temperature has dropped below the user set activation temperature. Water Heater Booster to utilize existing electrical infrastructure of electric tank water heater. Water Heater Booster compatible with gas tank water heater using dedicated 30 amp breaker. Water Heater Booster to be mounted in horizontal orientation with inlet on the bottom and outlet on the top.

Features

• Vacation Mode: Works with electric tanks to power off the tank when away on vacation
• Eco Mode: Works with electric tanks to conserve energy by turning the tank on and off on a set schedule
• Activation Temperature: Set inlet temperature at which the Water Heater Booster activates
• Freeze Protect: Works with electric tanks to automatically power on the tank if the Water Heater Booster inlet thermistor senses that the tank outlet has dropped below 60°F
• Max Temperature: Set the maximum temperature that the Water Heater Booster will heat up to
• Installs on Electric or Gas Tank
• Increase deliverable hot water up to 45%
• Compact design
• Digital user interface
• Set temperature in increments of 1°F
• Easy installation on new or existing water heater
• No need for additional electrical infrastructure if installed on existing electric water heater. Additional wiring maybe required for a gas tank installation.
• 5-Year heating chamber and 1-year parts limited warranty
